LLW555: Force Washer Load Cell
Force Washer Load Cell.
Capacities : +/- 2000 Lb.
Rated output : 0.8 mV/V.
Non Linearity : 1 %.
Central hole diameter : 1 3/4" [44.5 mm].
Operating Temperature : -60 to 212 °F (-50 to 100 °C).
Material : Anodized Aluminum.
Cable output.
Log in to your account to display prices
Login
Login
Applications
> <The LLW555 is a Load Washer Load Cell built for Press or Inline compression applications. The LLW555 Load Washer Load Cell standard model has a very robust construction available in 17-4 Stainless Steel with Anodized Aluminum cover, with a 2.98” outside diameter, and a 5 feet long 26 AWG 4 conductor spiral shielded Teflon cable.
The Load Washer Load Cell offers high stiffness with a Deflection of 0.001” nominal and Operating temperature of -60° F to 212° F. The Load Washer Load Cell can be modified or customized to meet your requirements and most capacities are in our inventory, making them available for quick delivery. Similar to our entire Load Cell product line this model is manufactured in the USA and uses metal foil strain gauge technology.
LLW555
Force Washer Load Cell.
Capacities : +/- 2000 Lb.
Rated output : 0.8 mV/V.
Non Linearity : 1 %.
Central hole diameter : 1 3/4" [44.5 mm].
Operating Temperature : -60 to 212 °F (-50 to 100 °C).
Material : Anodized Aluminum.
Cable output.
