Data acquisition
Sensel Measurement commercializes and designs a large range of solutions for data acquisition, compatible with almost types of sensors.
The acquisition solutions are:
1. Conditioning systems for USB sensors, directly connected.
2. Mono channel display for sensor with USB output
3. Wireless sensor networks these solutions use an acquisition software allowing the acquisition, the analysis and the graphical display of the data.
- PC Data acquisition.
- USB 2.0 Communication Link.
- Sampling Rate: up to 4800 Samples Per Second.
- mV/V input (selectable up to ± 500 mV/V).
- High resolution, high accuracy and low non-linearity.
- Weight: 10 gr.
PC Data acquisition.
USB 2.0 Communication Link.
Sampling Rate: up to 4800 Samples Per Second.
Amplified (Voltage or Current) input (selectable up to ±10V or 0-20 mA).
Amplified (Voltage or Current) input (selectable up to ±10V or 0-20 mA).
High resolution, high accuracy and low non-linearity.
Weight: 10 gr.
- External USB Kit (Amplified/Non Amplified + Encoder Input).
- 5 to 4800 sample per second selectable rate.
- High accuracy (±0.001%).
- Input range up to ±400mV/V (Strain Gauge), ±10VDC, up to 30 mA (Amplified Input).
- Output for encoder purpose.
- Selectable 5, 9, 10, 12, 15, 18, 20 and 24 VDC for sensor power.
- Speed/Angle/Power Measurement.
- Communication protocol :
- - TCP/IP 100BASE-TX (MG80-NE)
- - Ethernet/IP (MG80-EI)
- - PROFINET (MG80-PN)
- Transmission speed: 100 Mbit/s
- Functions: Resolution setting (0.1 to 10 µm), Reference point setting, Reset, Preset, Current value, Max value, Min value, Peak-to-peak value, Calculation function (2-axis addition and subtraction), Comparator.
- Mounting: 35 mm DIN rails
Highly accurate measurement results without linearity errors.
Channels 1 and 2 channel
Output signals analog: 4...20 mA / 0...10 V; digital: USB, CAN
Resolution 16 bit
frequency selectable, up to 20 kHz
compatible with eddylab software, linearisation and calibration function
As a platform should also include the software that collects, graphs and interprets your data FUTEK developed a software that does just that. SENSIT Test and Measurement - a software suite that expands the capabilities of a traditional sensor platform into an ultimate test-measurement solution.
Electronic for eddy current probes
High precision measurement
High resolution (submicrometer)
High dynamics (124 kSa/s
Minimal temperature coefficient
High noise immunity
Electronic for eddy current probes
High precision measurement
High resolution (submicrometer)
Output 10V
High dynamics (124 kSa/s
Minimal temperature coefficient
High noise immunity
- Analog inputs :
- - CR800 : 3 differential or 6 simple inputs
- - CR1000 : 8 differential or 16 single-ended inputs
- Compatibility: Fissurometer, Extensometer, Inclinometer, Piezometer and Strain Gauge
- Resolution: differential: 0.013% / simple: 0.026%.
- Analog outputs :
- - CR800: 2 switched voltages, active only during measurement, one at a time
- - CR1000: 3 switched voltages, active only during measurement, one at a time
- Operating temperature : -25°C to +50°C
- Accuracy : ±(0.12% of the range + 0.8 mV)
- Protection : IP65
